PIR Motion Sensor – Ultra QS – 09 – 180 Degree


Product Brochure


Download






Usage Area
Indoor / Outdoor
Application
Home Automation
Model / Type
Ultra-QS-09
Brand
Ultra
Supply Voltage
220–240 V AC
Power Frequency
50 Hz
Power Consumption
0.9 W (Working)
Rated Load
1200 W (Incandescent Lamp)
Output Type
Relay
IP Rating
IP65
Detection Angle
180°
Detection Motion Speed
0.6 ~ 1.5 m/s
Sensor Range
1.6 m
Installing Height
1.8 m ~ 2.5 m
Ambient Light
3–2000 LUX (Adjustable)
Time Delay
Min 10 sec ±3 sec, Max 8 min ±2 min
Working Temperature
-20°C to +40°C
Working Humidity
<93% RH
